Grundfos CRN5-24 A-FGJ-G-E-HQQE 3x400D 50HZ
Product ID: 96514208

CRN 5-24 A-FGJ-G-E-HQQE
垂直的,on-self-priming, multistage, in-line, centrifugal pump for installation in pipe systems and mounting on a foundation.

The pump has the following characteristics:

The motor is a 3-phase AC motor.

Order information

Download PDF

Specifications

Controls:
Frequency converter:		NONE

Liquid:
Pumped liquid:		水
Liquid temperature range:		-20 .. 120 °C
Liquid temperature during operation:		20 °C
Density:		998.2 kg/m³

Technical:
Speed for pump data:		2917 rpm
Rated flow:		5.8 m³/h
Rated head:		125.5 m
Pump orientation:		垂直
Shaft seal arrangement:		Single
Code for shaft seal:		HQQE
Approvals on nameplate:		CE, EAC,ACS
Curve tolerance:		ISO9906:2012 3B

Materials:
Base:		Stainless steel
		EN 1.4408
		AISI 316
Impeller:		Stainless steel
		EN 1.4401
		AISI 316
Bearing:		SIC

Installation:
Maximum ambient temperature:		60 °C
Maximum operating pressure:		25 bar
Max pressure at stated temp:		25 bar / 120 °C
		25 bar / -20 °C
Type of connection:		DIN / ANSI / JIS
Size of inlet connection:		DN 25/32
		1 1/4 inch
Size of outlet connection:		DN 25/32
		1 1/4 inch
Pressure rating for pipe connection:		PN 25
Flange rating inlet:		300 lb
Flange size for motor:		FT130

Electrical data:
Motor standard:		IEC
Motor type:		112MC
IE Efficiency class:		IE3
Rated power - P2:		4 kW
Power (P2) required by pump:		4 kW
Mains frequency:		50 Hz
Rated voltage:		3 x 380-415D V
Rated current:		7.9 A
Starting current:		1000-1110 %
Cosφ-功率因数:		0,87-0,87
Rated speed:		2920-2940 rpm
Efficiency:		IE3 88,1%
Motor efficiency at full load:		88.1 %
Motor efficiency at 3/4 load:		88.6 %
Motor efficiency at 1/2 load:		85.2 %
Number of poles:		2
Enclosure class (IEC 34-5):		55 Dust/Jetting
Insulation class (IEC 85):		F

Others:
Minimum efficiency index, MEI ≥:		0.57
Net weight:		65.1 kg
Gross weight:		69.8 kg
Shipping volume:		0.148 m³
